NSX-5000H

High-Precision Measurement of Nitrogen, Sulfur & Chlorine in Liquid and Solid Samples

The NSX-5000H series from Nittoseiko is an advanced horizontal-furnace trace elemental analyzer designed for fully automated, safe, and ultra-sensitive quantification of nitrogen (N), sulfur (S) and chlorine (Cl) in liquid (non-aqueous) and solid samples. Engineered to support environmental sustainability through reduced gas consumption and optimized workflows, it delivers robust analytical performance for routine QC and high-level research laboratories.

Ideal for the petroleum, chemical, recycled fuels, automotive, and environmental analysis sectors, the NSX-5000H offers exceptional reproducibility, fast measurement cycles and simplified operation.

Key Features & Advantages

🖥️ User-Friendly Software

Two operation modes ensure accessibility for all experience levels:

• Simple Mode – for routine QC and fast everyday operation
• Advanced Mode – for detailed method creation, audit trail review and system configuration

🚀 Rapid Analysis with Automatic Sample Boat Control

The analyzer automatically introduces the sample boat into the furnace with precisely controlled speed, preventing incomplete combustion and ensuring:

• Stable, reproducible combustion
• Shorter measurement times
• Accurate trace-level detection

New measurement programs can be created quickly and easily.

💲 Low Operating Cost

• Reduced gas consumption compared to previous models
• Automatic gas shut-off after measurement

→ Lower environmental load and reduced running costs

🛠️ Easy Daily Maintenance

The open/close horizontal furnace design enables:

• Quick visual inspection of pyrolysis tube condition
• Easy replacement of components
• Simplified routine maintenance

🔐 Compliance, Data Integrity & Automation

• Audit Trail – complete logging of all operations for regulatory compliance
• User Management (3 access levels) – prevents unintended edits to methods or data
• Automatic Start-Up / Shut-Down – fully programmable temperature and gas-flow sequences
• Reanalysis Function – adjust measurement start/end time after acquisition

📊 Standard Specifications

	Sulfur	Nitrogen	Chlorine	Sulfur
Detector	SD-500	ND-500	MCD-500
Sample	Liquid (non-aqueous) / Solid		Liquid / Solid

Analytical method	UV fluorescence	Chemiluminescence	Micro coulometry
Furnace	Max. 1,100℃, Openable electric furnace, 2-section type
Measuring range	Liquid: 0.05 – 10,000µg/ml Solid: 0.1 – 10,000µg/g	Liquid: 0.05 – 10,000µg/ml Solid: 0.5 – 10,000µg/g	Liquid: 0.1 – 5,000µg/ml Solid: 0.5 – 50,000µg/g	Liquid: 0.2 – 1,000µg/ml Solid: 1.0 – 5,000µg/g
Sample volume	Liquid: Max 100μl, Solid: Max 30mg
Measurement time	Approx. 8 min. depending on the sample volume and measurement condition		Approx. 10 min. for 2μg Cl/S
Gas used	Argon: Purity 99.98% or more, 0.3±0.1 MPa, Oxygen: Purity 99.7% or more, 0.3±0.1 MPa
Power supply	HF-500: AC100 / 115V (50 / 60 Hz), 1,100 VA AC230/ 240 V, (50/ 60 Hz), 1,800 VA SD/ ND/ MCD-500: AC100 – 240 V, 300 VA
Mass and weight	HF-500: 320 (W)×430 (D)×500 (H) mm, approx. 25 kg, SD-500: 220 (W)×375 (D)×500 (H) mm, approx. 21 kg, ND-500: 220 (W)×375 (D)×500 (H) mm, approx. 22 kg, MCD-500: 220 (W)×370 (D)×500 (H) mm, approx. 14 kg,

🌍 Applications

The NSX-5000H is ideal for:

• Petroleum & petrochemical quality control
• Analysis of chemical and recycled products
• Automotive fuel testing
• Environmental monitoring (wastewater, soil, industrial residues)
• Research laboratories requiring trace-level element quantification

Why Choose the Nittoseiko NSX-5000H?

✔ High-sensitivity analysis across wide dynamic ranges

✔ Supports both liquid and solid sample matrices

✔ Lower environmental impact due to reduced gas usage

✔ Automated workflows with advanced furnace control

✔ Easy maintenance through unique openable furnace design

✔ Full regulatory support with audit trail & user management

✔ Reliable performance for QC, R&D and environmental analysis

📌 For complete technical specifications, optional accessories and detailed documentation, visit the official Nittoseiko NSX-5000H product page.
